SPECIFICATIONS
| Laser Type | 1080 NM Fiber laser |
| Nominal Laser Power | 1000W/1500W/2000W |
| Cooling System | Water Cooling |
| Way of Working | Continuous/Modulation |
| Speed Range Of Welder | 0-120 mm/s |
| Focal Spot Diameter | 0.5 mm |
| Ambient Temperature Range | 15-35 C |
| Enviromental Humidity Range | <70% Without Condensation |
| Welding Thickness | 0.5-3mm |
| Welding Gap Requirements | <-1.2 mm |
| Operating Voltage | AV 220 mm |
| Machine Dimensions | 660*1150*1150mm(Orange)/720*1050*1180mm(Blue & white,red) |
| Packing weight | 125 Kg (approx) |
| Fiber Length | Standard 10m,longest Customized length 15m |
