SPECIFICATIONS
Model | LT-3015DP | LT-4020DP |
power(KW) | 1kw-30kw | 1kw-30kw |
Cutting Range(L*W) | 3000*1500mm | 4000*2000mm |
Z axis Track | 100mm | 100mm |
Positioning Accuracy | ± 0.04mm | ±0.04mm |
Repeatability | ±0.02mm | ±0.02mm |
Maximum Position speed | 120m/min | 120m/min |
Maximum Acceleration | 1.2G | 1.2G |
Power Requirement | 380V,50/60Hz | 380V,50/60Hz |
Working Temperature | 5C-45C | 5C-45C |
Power supply Protection Level | IP54 | IP54 |
Driven System | Imported Double Drive | Imported Double Drive |
